Benefits of a Campaign Manager
Batch processing facilitates the repetitive, tightly controlled manufacture of many things. This type of operation is ideal for large scale manufacturing where products are assembled and modified in a series of stages or steps. When connected to a batch management software system, the number of ingredients, execution stages, and degree of processing complexity which can be handled by relatively unsophisticated operators can be extraordinary. The typical end results for manufacturers are lower cost per unit products with tight quality control and meticulous records of production.
Enterprise resource and scheduling systems are ubiquitous to modern manufacturing organizations. These are frequently mated to plant floor automation systems. For simple batch operations with savvy operators this task can be straightforward, particularly when aided by a batch management solution. However, in operations that require rapid processing or changeover between many in-progress batch orders, this can be challenging. The same is true if batch processing requirements for a single order are large in either complexity or an amount of time that spans beyond the purview of a single operator or team. Integration between the master resource and scheduling system and the batch operating environment can be enhanced using a campaign manager.
Read More | Posted In: Bakery Industry, Beverage Industry, Blogs, Chemical Industry, Consumer Goods, Distilleries, FactoryTalk Batch, Food Industry, Inductive Automation, Life Science Industry, Metals, Metals Industry, News
12 Batch Implementation Design Considerations
Batch systems are used for maximizing quality control, minimizing cost, and reducing loss by manufacturing smaller batches compared to a mass production model, which is why companies in the food and beverage, pharmaceutical, and chemical industries rely on them. The audience of a batch system is varied, and therefore the proper implementation of a batch system needs to consider many factors. From the Plant Manager, Operations, Engineering, and Maintenance to the Operators, all these personas have unique needs that must be considered.
The best practices dictated by standards such as ISA 88 and ISA 95 provide a great guideline or starting point, but these standards do not prescribe how to implement the details of a solution. Therefore, the following is intended to highlight some of the considerations for a system design.
Creating a Robust Equipment Model for Optimal Plant Performance
A plant’s capabilities of what and how products can be manufactured there reside in the capabilities of its equipment, materials, and personnel. These capabilities are captured by the Equipment Model as defined in ISA 88 & 95. Once you capture these capabilities, they are exposed to the recipe author to define how to execute the product manufacturing workflow, which is detailed in the ISA 88 Procedural Model.
Having a well-defined Equipment Model is paramount to enabling the plant’s maximum capabilities while providing the recipe author and operators with an intuitive experience. The Equipment capabilities definition should include the activities that the automation controls system can perform (i.e., Add Water) as well as the activities performed by the operators and other personnel (i.e., Manual Additions, Lab Sample Data, etc.).
Read More | Posted In: Bakery Industry, Beverage Industry, Blogs, Chemical Industry, Consumer Goods, Distilleries, Inductive Automation, Life Science Industry, Metals Industry
A Trusted Advisor Cements Their Value During Project Startups
Engineering projects may take extended periods of time to develop and physically install, often with macro progress being tough to gauge on a day-to-day basis. These efforts come to a head with a flurry of activity in the final hours before “go live”. Tradesmen flutter about making final adjustments to installed bulk hardware and intricate instruments, electricians frantically make and test terminations, and supervising engineers and integrators follow about ensuring that checklist items are noted and addressed. These activities can resemble an orchestral presentation that might span multiple shifts for days and weeks on end. It is at this time that the systems integrator proves their value and clients learn that having a true trusted advisor is critically important to success.
There was a time where simple catch all language could be inserted into automation project contracts and a client could fairly expect an integrator to ensure that a system was complete. Language like “systems integrator must include all miscellaneous items required to make a complete system” would be included in specifications. This verbiage would cover small things like signal conditioning hardware and loop tuning labor and/or tools and it was reasonable to expect that the integrator could include “everything”. The definition of complete has changed considerably over the last decade. Factories today are far more complex, and the plant automation systems are interwoven into every part of many organizations. Protection language like those mentioned before would be wholly inadequate in covering the breadth of items that intermingle with the controls today. Furthermore, attempts to bind project contracts with far-reaching, boilerplate language would leave enormous gaps in functionality that would render most systems a shell of what is truly possible with modern technology.
Read More | Posted In: Bakery Industry, Beverage Industry, Chemical Industry, Consumer Goods, Distilleries, Food Industry, Life Science Industry, Metals Industry, News
ECS Delivers True Long Term Success as Trusted Advisors
People and organizations leverage trusted advisors in all facets of life. Whether it is something as commercial as an auto mechanic or as intimate as a primary care physician, attorney, or wealth advisor, trusted advisors play a role just about everywhere. They maintain deep, current knowledge in specialized fields, and they stand ready to support those in need. They are driven by excellence, thinking beyond themselves or their own organization and focus on the broader environment. Where their focus intersects with the needs of a client, a true trusted advisor relationship can take hold.
Control systems integration is young but maturing when compared to many other functions in legacy buildings and operations. The discipline, which barely existed a generation and a half ago, has become the technological focal point of modern manufacturing. There are no lulls or definable steps as technology continually advances at a dizzying pace. What started as ways to simplify wiring and logic applied to flexibility in controls has evolved into a holistic environment which links manufacturing, operations, and supply chains via a web of connected people and equipment. Manufacturers leverage related professionals each day to stay at the edge of technology and to apply it effectively.
ECS Solutions (ECS) has been around since the dawn of the systems integrator-for-hire concept. Our success has been driven by working collaboratively with our clients as true strategic partners. We know that enduring bonds do not develop by accident nor out of contractual obligation. Our clients expect that we know not only where technology is today, but also where it is going. They leverage our extensive knowledge and experience in ways that address both their immediate needs and their continuing objectives.
Read More | Posted In: Bakery Industry, Beverage Industry, Blogs, Chemical Industry, Consumer Goods, Distilleries, Food Industry, Life Science Industry, Metals Industry, News
KNOW YOUR LOOP BEFORE YOU ATTEMPT TO TUNE YOUR LOOP – PART 2
In the last article for this topic, we discussed the importance of field data collection and the importance of a methodical approach to PID tuning. I introduced the concept of the bump test and that its results would help guide the steps and equations used in proper tuning. Here I will explore that concept in greater detail. At ECS we use a visual tool for data collection in every instance. The tool may be part of a controller suite, or it may be stand-alone but, in any case, it is imperative to capture accurate information about the performance of your system before planning and then programming a solution.
In the interest of time, this article will focus on tuning concepts for self-regulating loops as they make up the majority of applications in the industrial field. A common example of this type of loop is a flow control which varies flow through a pipe via either variable speed control on a pump or a position-controlled valve. In this example, the flow can be adjusted by speed adjustment of the pump or position of a valve and the result of the change ordered from the controller is stable and is generally fast and repeatable.
Read More | Posted In: Beverage Industry, Blogs, Chemical Industry, Consumer Goods, Food Industry, Life Science Industry
Innovative Tools for the Evolving Systems Integrator
The personnel challenges facing virtually every industry over the last few years have been nothing short of astonishing. Proper candidates have become increasingly difficult to court and bring on board. New staff in key roles are tasked to accomplish more with fewer floor operators and technology is increasingly leveraged to close the resulting gaps. This is not unique in history although it may seem that way due to the current media deluge surrounding business intelligence and general-purpose visibility software that makes life easier, smarter, and generally more efficient.
Industrial software is again playing a leading role in the current intelligence revolution. Inductive Automation didn’t invent floor supervisory (SCADA) software, nor did they invent the first responsive, general-purpose web software. However, their current offerings certainly do marry these concepts together in a way that hasn’t existed in industry before. Since 2010 their award-winning Vision Module has enhanced the experiences of factory floor users everywhere, easily connecting complex factory controllers to databases, alarm and reporting systems, and intuitive visualization tools. This product is robust, proven, and works very well for users “inside the industrial network” of many facilities. Today this is coupled with the newer Perspective Module which is an equally powerful tool for use in mobile-responsive applications. For situations where a user may be “outside the industrial network” or simply need to utilize a variety of hardware platforms like PCs, phones, or tablets, Perspective provides an ideal solution.
Read More | Posted In: Bakery Industry, Beverage Industry, Blogs, Chemical Industry, Consumer Goods, Food Industry, Inductive Automation, Life Science Industry, Metals Industry, SCADA
Case Study: An Upgrade to Ignition Sepasoft “Perspective” OEE & Downtime Module
A global consumer goods manufacturer hired ECS Solutions to evaluate and install an upgrade of an Ignition Application from Version 7.9 to Version 8.1. Version 7.9 was originally installed by ECS Solutions. The overall objective for the company was to have a web-based client application that was independent of Java and based on HTML5. The upgrade included a reconfiguration of the MES software to improve its effectiveness.
The previous Ignition “Vision”-based Application did provide the functionality to monitor Equipment Downtime and Overall Equipment Effectiveness (OEE), but the use of Java within the Ignition modules conflicted with other applications at the site and made it difficult to access throughout the organization. Migration to the web-based Perspective Platform allowed ECS to significantly lighten the application and to focus on the most important data. The new version of the Sepasoft OEE module also made it possible to simplify how the workstream was modeled within the Sepasoft Production module. The company required this application be designed to work with both PCs and iPads.
Read More | Posted In: Consumer Goods
Large Consumer Goods Case Study
THE CHALLENGE
ECS was hired to upgrade and replace a CIP control system in one of the manufacturing areas for a large consumer goods company. The scope of work included a new control enclosure containing an upgrade from a SLC5 controller to a ControlLogix controller. The upgrade also consisted of all IO and connections within the enclosure. Additionally, the company wanted to solve the problem of inefficiencies in its CIP process by implementing FactoryTalk Batch and Batch control within this updated CIP system.
Read More | Posted In: Case Studies, Clean in Place, Consumer Goods
